Dürr Dental VistaScan Mini Plus
MYR40,000.002 items left
The product selection is not available.
Product Description:
Dürr Dental VistaScan Mini Plus – “red dot design award winner 2011“
VistaScan Mini Plus

VistaScan Mini Plus – “red dot design award winner 2011“

Since the introduction of conventional X-ray film development in dentistry, Dürr Dental has been at the cutting edge of diagnostics in the surgery.

Digital X-ray with Dürr Dental offers dentists images with high resolution to meet all diagnostic demands.

More than 50 years' experience in the development of X-ray technology leads time and again to practice-oriented and innovative solutions.

The VistaScan Mini image plate scanner makes image plate diagnostics even faster for dentists. The compact device is particularly easy to use and requires a minimum of space – so that it can be installed in the treatment room.

The advantage:

X-ray and scanning directly at the chairside with full flexibility in the image formats. The re-usable VistaScan image plates are read out in top quality within seconds.There's never been a better time to change over to plates.

VistaScan Mini Plus – compact without compromise

The grey scale graduation of the image plate with VistaScan Mini permits a presentation commensurate with the quality of the plate. With the proven engineering and outstanding image quality characteristic of Dürr Dental image plate scanners worldwide. Made in Germany.

No compromises on image quality
Thanks to PCS technology, VistaScan Mini can reliably resolve caries D1 lesions and endoinstruments down to ISO 06. With 22 LP/mm, 16-bit (65.536) grey scales.

No compromises on flexibility
All intraoral image plates – from size 0 to 4 – can be used with VistaScan Mini. In addition, 100% active surface area is available. Simple handling – as with an analog film.

No compromises on simplicity
Particularly easy handling: Read out, delete and make ready for the next use in one step. Rapid image availability from 6 seconds on in the direct vicinity of the patient.

No compromises on configuration
The display shows the most important patient data and information on the scanning process at a glance. Including energy-saving stand-by function.
No compromises on integration
VistaScan Mini can be operated with DBSWIN or other software packages via plug-ins or Twain drivers.It can be easily integrated into the surgery infrastructure via the USB or network interface.

Highest image quality, perfect presentation

With a detail recognition of 22 LP/mm, VistaScan image plates have a higher resolution than the X-ray film and exceed that of any competitors. The Photon Collecting System (PCS) from Dürr Dental is already ahead of current image plate developments.
That means:
In diagnostics you are well-prepared for the future with this compact solution. The DBSWIN imaging software displays the results in brilliant quality and allows ergonomic working procedures. The VistaScan Mini can be operated with most standard dental imaging software packages.

Faster and more reliable diagnostics

Changeover from X-ray film to "digital" image plate? There's nothing easier than that. the X-ray exposure procedure remains the same as before. However, the diagnostic reliability is increased thanks to optimum detail recognition and sophisticated software support. With the VistaScan Mini you can benefit from all the advantages of the Dürr Dental image plate technology in its most compact form. The thin, flexible image plates are more pleasant for the patient and are particularly durable thanks to their special coating.

Technical data

VistaScan Mini Plus



Plate sizes

0 to 4

Effective resolution (LP/mm, dpi)

22; 1,100

Theoretical resolution (LP/mm, dpi)

40; 2,000

Weight (kg)


Dimensions (H x W x D mm)

226 x 234 x 243

Stand-by function



USB/ network
